Stealth XLT

Prices and Packages

Stealth XLT, TenPoint Crossbow Technologies

The Stealth XLT will be provided with following:

  • 4 x 32 scope
  • ACU Draw 50
  • 3 arrows
  • quiver
  • incl. 1,5-5x32 Rangmaster scope (1.289,- EUR)
Crossbow from our model archive.
This model is no longer manufactured and is no longer available. Questions regarding accessories, spare parts or successor models: Contact or use leaflet.
Der Merkzettel kann als unverbindliche Anfrage gesendet werden.
As German direct importer for crossbows of TenPoint Crossbows we offer full technical service, many years of experience, complete spare parts in stock as well as qualified advice.

Technical specification

Name
Stealth XLT
Manufacturer
TenPoint Crossbow Technologies
Type (Compound/Recurve)
Compound
Draw weight
185 lbs
Weight
3.6 kg
Powerstroke
12 Inch
Teflon impregnated
Yes
Dryfire protection
Yes
Hollow machined track
No
Number of limbs
4
CNC machined riser
Yes
Sight base included
Yes
Length incl. stirrup
37 Inch
Bowstring material
DynaFlight
Country
USA
Trigger safety
Yes
Triggerweight
3,5 lbs
Trigger safety autom
Yes
Withdrawal force
-
Overall width
19,7 Inch
Dampening system
No
Length without stirrup
34,6 Inch
Loudness (tendency)
sehr leise
Triggersystem
nach oben öffnend
String and cablesystem
uniform
Total mass
7,94 lbs
Specifics
-

Arrow speed

  • Minimalarrow ( grain):
    Arrow speed
    -
    -
    -
    Arrow energy
    -
    -
  • Idealarrow ( grain):
    Arrow speed
    98 m/s
    352,8 km/h
    320 fps
    Arrow Energy
    134,8 Joule E0
    99,4 ft ft. lbs
  • Standardarrow (506 grain):
    Arrow speed
    -
    -
    -
    Arrow Energy
    -
    -

Matchin crossbowarrows

Arrow weight
-
Shaft spline carbon
2264
Shaft spline alu
2219
Arrow length
20 Inches
min. arrow diameter
8,7 mm

Range

  • max. adjustable range with scope and accessories (elevation scope mount):
    Range
    143 yard
  • max. range standardvisor:
    Range
    66 yard
