Darton Storm

Manufacturer: Darton Archery

Alle Fotos

Prices and Packages

Storm, Darton Archery

The Storm will be provided with following:

portofreier Versand innerhalb Deutschland und Österreich
4 x 32 AIA Zielfernrohr und 3 Pfeilen
Zielfernrohrschiene - Weaver 22mm, Trockenschusssicherung, verstellbare Pfeilniederhalter Feder, in der Länge verstellbares Schaftende

Crossbow from our model archive.
This model is no longer manufactured and is no longer available. Questions regarding accessories, spare parts or successor models: Contact.

As German direct importer for crossbows of Darton Archery we offer full technical service, many years of experience, complete spare parts in stock as well as qualified advice.

Recommended accessories

Technical specification

Type: Compound
Draw weight: 175 lbs; 79 kg
Powerstroke: 15,5 "; 39,4 cm
Teflon impregnated: yes
Dryfire protection: yes
Hollow machined track: yes
Number of limbs: 4
CNC machined riser: yes
Sight base included: yes
Length incl. stirrup: 35 "; 89 cm
Bowstring material: DynaFlight
Country: USA
Trigger safety: yes
Triggerweight: 3 lbs; 1,3 kg
Trigger safety autom: no
Overall width (de-cocked): 28,4 "; 72,1 cm
Dampening system: no
Length without stirrup: 31,3 "; 79,5 cm
Loudness (tendency): very quiet
Triggersystem: nach oben öffnend
String and cablesystem: uniform
Total mass: 8,3 lbs; 3,7 kg

Manufacturer's information:
Darton Archery, 3540 Darton Rd. Hale, MI 48739, USA
dartonarchery.com

Responsible person:
AIA Pfeilsport GmbH, Schillerstr. 70, 16341 Panketal

E-Mail:
info@pfeilsport-gmbh.de

Arrow speed

Minimalarrow 425 grain (27,5 g):
Arrow speed
346 fps
105 m/s
Arrow energy
E₀ 151 Joule
E₀ 111 ft-lb
Idealarrow 489 grain (31,7 g):
Arrow speed
334 fps
102 m/s
Arrow energy
E₀ 164 Joule
E₀ 121 ft-lb
Standardarrow 506 grain:
Arrow speed
329 fps
100 m/s
Arrow energy
E₀ 165 Joule
E₀ 122 ft-lb

Matchin crossbowarrows

Arrow weight(s): 489 grain; 31,7 g
Shaft spline carbon: 2264
Shaft spline alu: 2219
Arrow length(s): 22 "
20 "; 55,9 cm
50,8 cm
Min. arrow diameter: 8,73 mm; 0,3437 "

Range

max. adjustable range with scope and accessories (elevation scope mount):
Range
100 m
109 Yard
max. range standardvisor:
Range
100 m
109 Yard
