Great Lakes Stinger

Prices and Packages

Stinger, Great Lakes Crossbows

The Stinger will be provided with following:

  • 4 x 32 BSA AR scope with scope rings for the weaver bar
  • 3 arrows
  • scope mount
  • Bow - dampening package
  • adjustable butt plate for a custom fit
  • free shipping within Germany
Crossbow from our model archive.
This model is no longer manufactured and is no longer available. Questions regarding accessories, spare parts or successor models: Contact.
As German direct importer for crossbows of Great Lakes Crossbows we offer full technical service, many years of experience, complete spare parts in stock as well as qualified advice.

Description

Shooting with the Stinger is a real pleasure The compact design and the good handling are making this crossbow that popular.

The manufacturer (Darton) produces compound-crossbows for over 50 years and infuses his entire experience into the Great Lakes series. Unmistakably highest speeds, power and precision are being implemented through remarkable engineering skills.

Like all Great Lakes models the Stinger is sound and manufactured with high-quality materials. All parts important for shooting are milled from a high-quality aluminium alloy and impregnated with Teflon. One has alway a very good feeling and is equally surprised how soft and calm this crossbow is behaving at the point of firing.

The European Record in 3D shooting of the EAA is still hold with Great Lakes’ models.

How accurate does it shoot?

 Stinger 2006 (884)

A new ergonomically formed stock with triple adjustable shoulder-support makes the crossbow not only more attractive, but guarantees a balanced and calm shooting position.

The stock profile for the stützhand is especially formed, in order to prevent the shooter from accidentially touching the chord’s way. A complete dampening package on the limbs, the chord an the arrow downholder are creating the Stinger to be one of the most silent crossbows.

The Stinger has a 1,5“ shorter draw length than the Impact but ranks nevertheless second on the world market regarding the arrow energy after her bigger brother. It is to be said that the reasons therefor are to be found by the heavier arrows and the higher arrow speeeds. Arrow speeds of 330fps with a 480grain (31,00g) arrow have been measured with the Stinger. This equals about 101 m/s or 362 km/h.

Technical specification

Type
Compound
Draw weight
165 lbs
75 kg
Powerstroke
15,5 "
39,4 cm
Teflon impregnated
yes
Dryfire protection
yes
Hollow machined track
yes
Number of limbs
4
CNC machined riser
yes
Sight base included
yes
Length incl. stirrup
37,4 "
95 cm
Axle to axle bow width (de-cocked)
26,8 "
68 cm
Bowstring material
DynaFlight
Country
USA
Trigger safety
yes
Triggerweight
3,5 lbs
1,6 kg
Trigger safety autom
no
Withdrawal force
736 N
Overall width (de-cocked)
28,7 "
73 cm
Dampening system
yes
Length without stirrup
33,7 "
85,5 cm
Loudness (tendency)
very quiet
Triggersystem
nach oben öffnend
String and cablesystem
uniform
Total mass
8,4 lbs
3,8 kg
Specifics
  • ergonomic stock
  • 8 arrow quiver mountable (optional)
  • shoulder sling mountable
  • 2 different cocking aids applicable
Manufacturer's information:
Darton Archery, 3540 Darton Rd. Hale, MI 48739, USA
dartonarchery.com

Responsible person:
AIA Pfeilsport GmbH, Schillerstr. 70, 16341 Panketal

E-Mail:
info@pfeilsport-gmbh.de

Arrow speed

  • Minimalarrow 460 grain (29,8 g):
    Arrow speed
    333 fps
    101 m/s
  • Idealarrow 480 grain (31,1 g):
    Arrow speed
    330 fps
    101 m/s
    Arrow energy
    E0 162 Joule
    E0 119 ft-lb
  • Standardarrow 506 grain:
    Arrow speed
    327 fps
    100 m/s

Matchin crossbowarrows

Arrow weight(s)
480 grain
31,1 g
Shaft spline carbon
2264
Shaft spline alu
2219
Arrow length(s)
22 "
55,9 cm
Min. arrow diameter
8,73 mm
0,3437 "

Range

  • max. adjustable range with scope and accessories (elevation scope mount):
    Range
    85 m
    93 Yard
  • max. range standardvisor:
    Range
    140 m
    153 Yard
