TenPoint Carbon Fusion CLS

Manufacturer: TenPoint Crossbows

Alle Fotos

Prices and Packages

Carbon Fusion CLS, TenPoint Crossbows

The Carbon Fusion CLS will be provided with following:

BowJax dampening system
Arrow quiver for 3 arrows
AIA FRS 101-12 scope - adjustetable arrow speed
SDS dampening system, TenPoint compact case
TenPoint compact case
6 x carbon arrows
3 Safety systems, Dry fire inhibitor, automatic loading safety, finger savety
ACU DRW 50

Crossbow from our model archive.
This model is no longer manufactured and is no longer available. Questions regarding accessories, spare parts or successor models: Contact.

As German direct importer for crossbows of TenPoint Crossbows we offer full technical service, many years of experience, complete spare parts in stock as well as qualified advice.

Recommended accessories

Technical specification

Type: Compound
Draw weight: 185 lbs; 84 kg
Powerstroke: 13 "; 33 cm
Teflon impregnated: no
Dryfire protection: yes
Hollow machined track: no
Number of limbs: 4
CNC machined riser: yes
Sight base included: yes
Length incl. stirrup: 38 "; 96,5 cm
Axle to axle bow width (de-cocked): 20,5 "; 52,1 cm
Bowstring material: DynaFlight
Country: USA
Trigger safety: yes
Triggerweight: 3 lbs; 1,4 kg
Trigger safety autom: yes
Overall width (de-cocked): 23 "; 58,4 cm
Dampening system: yes
Length without stirrup: 36,5 "; 92,7 cm
Loudness (tendency): quiet
Triggersystem: Power Touch Trigger, nach oben öffnend
String and cablesystem: uniform
Total mass: 7,2 lbs; 3,3 kg

Manufacturer's information:
TenPoint Crossbow Technologies, 1325 Waterloo Road, Mogadore, OH 44260, USA
www.tenpointcrossbows.com

Responsible person:
AIA Pfeilsport GmbH, Schillerstr. 70, 16341 Panketal

E-Mail:
info@pfeilsport-gmbh.de

Arrow speed

Minimalarrow 401 grain (26 g):
Arrow speed
349 fps
106 m/s
Arrow energy
E₀ 147 Joule
E₀ 108 ft-lb
Idealarrow 432 grain (28 g):
Arrow speed
346 fps
105 m/s
Arrow energy
E₀ 156 Joule
E₀ 115 ft-lb
Standardarrow 506 grain:
Arrow speed
333 fps
101 m/s
Arrow energy
E₀ 169 Joule
E₀ 125 ft-lb

Matchin crossbowarrows

Arrow weight(s): 432 grain; 28 g
Shaft spline carbon: 2264
Shaft spline alu: 2119
Arrow length(s): 20 "; 50,8 cm
Min. arrow diameter: 8,73 mm; 0,3437 "

Range

max. adjustable range with scope and accessories (elevation scope mount):
Range
160 m
175 Yard
max. range standardvisor:
Range
70 m
77 Yard
