TenPoint Carbon Fusion CLS

Prices and Packages

Carbon Fusion CLS, TenPoint Crossbows

The Carbon Fusion CLS will be provided with following:

  • BowJax dampening system
  • Arrow quiver for 3 arrows
  • AIA FRS 101-12 scope - adjustetable arrow speed
  • SDS dampening system, TenPoint compact case
  • TenPoint compact case
  • 6 x carbon arrows
  • 3 Safety systems, Dry fire inhibitor, automatic loading safety, finger savety
  • ACU DRW 50
Crossbow from our model archive.
This model is no longer manufactured and is no longer available. Questions regarding accessories, spare parts or successor models: Contact.
As German direct importer for crossbows of TenPoint Crossbows we offer full technical service, many years of experience, complete spare parts in stock as well as qualified advice.

Technical specification

Name
Carbon Fusion CLS
Manufacturer
TenPoint Crossbow Technologies
Type (Compound/Recurve)
Compound
Draw weight
185 lbs
Weight
3,2 kg
Powerstroke
13 Inch
Teflon impregnated
No
Dryfire protection
Yes
Hollow machined track
No
Number of limbs
4
CNC machined riser
Yes
Sight base included
Yes
Length incl. stirrup
38 Inch
Bowstring material
DynaFlight
Country
USA
Trigger safety
Yes
Triggerweight
2,98 lbs
Trigger safety autom
Yes
Overall width
23 Inch
Dampening system
Yes
Length without stirrup
36,5 Inch
Loudness (tendency)
leise
Triggersystem
power Touch, nach oben öffnend
String and cablesystem
uniform
Total mass
7,2 lbs

Arrow speed

  • Minimalarrow (401 grain):
    Arrow speed
    106,5 m/s
    383,4 km/h
    349 fps
    Arrow energy
    147 Joule E0
    109 ft-lb (foot-pound)
  • Idealarrow (432 grain):
    Arrow speed
    105,5 m/s
    379,8 km/h
    346 fps
    Arrow Energy
    155,8 Joule E0
    115 ft-lb (foot-pound)
  • Standardarrow (506 grain):
    Arrow speed
    101,5 m/s
    365,4 km/h
    333 fps
    Arrow Energy
    169 Joule E0
    116 ft-lb (foot-pound)

Matchin crossbowarrows

Arrow weight
432 grain
Shaft spline carbon
2264
Shaft spline alu
2119
Arrow length
20 Inches
min. arrow diameter
8,73 mm

Range

  • max. adjustable range with scope and accessories (elevation scope mount):
    Range
    176 yard
  • max. range standardvisor:
    Range
    77 yard
